Kaishan KROF Series Oil-free Screw Air Compressor

Ensure 100% oil-free air with the Kaishan KROF series oil-free screw compressor. Certified to ISO 8573.1 Class 0, this advanced screw compressor delivers ultra-clean compressed air vital for pharmaceuticals, food processing, and electronics, preventing costly production downtime.
Featuring a PTFE-coated airend with a 5-year warranty, an IE3 motor, and a patented hydraulic intake valve, it guarantees reliable, low-noise performance. The smart HMI with RS485 networking and hot-cold zone separation ensures superior heat dissipation and easy maintenance. Trust this high-performance Kaishan compressor for safe, eco-friendly, and efficient industrial operations.
EMAIL US INQUIRY

开山KROF系列无油螺杆式空气压缩机参数
开山KROF系列无油螺杆式空气压缩机参数
Kaishan KROF Series Oil-Free Screw Air Compressor Specifications

型号 Model	排气压力(MPa) Working pressure	排气量(m³/min) Capacity	功率(kW) Power	排气接口 Outlet size	重量(kg) Weight	长(mm) Length	宽(mm) Width	高(mm) Height
KROF-45	0.7	7.23	45	DN65	2735	2300	1400	2100
KROF-45	0.8	6.07	45	DN65	2735	2300	1400	2100
KROF-45	1.0	4.66	45	DN65	2735	2300	1400	2100
KROF-55	0.7	9.35	55	DN65	2830	2300	1400	2100
KROF-55	0.8	7.97	55	DN65	2830	2300	1400	2100
KROF-55	1.0	6.58	55	DN65	2830	2300	1400	2100
KROF-75	0.7	12.95	75	DN65	3020	2470	1500	2200
KROF-75	0.8	12.55	75	DN65	3020	2470	1500	2200
KROF-75	1.0	10.01	75	DN65	3020	2470	1500	2200
KROF-90	0.7	15.79	90	DN65	3060	2470	1500	2200
KROF-90	0.8	14.12	90	DN65	3060	2470	1500	2200
KROF-90	1.0	11.86	90	DN65	3060	2470	1500	2200
KROF-110	0.7	18.65	110	DN80	4120	3435	1865	2250
KROF-110	0.8	18.57	110	DN80	4120	3435	1865	2250
KROF-110	1.0	15.57	110	DN80	4120	3435	1865	2250
KROF-132	0.7	22.50	132	DN80	4180	3435	1865	2250
KROF-132	0.8	22.42	132	DN80	4180	3435	1865	2250
KROF-132	1.0	20.53	132	DN80	4180	3435	1865	2250
KROF-160	0.7	27.78	160	DN80	4270	3435	1865	2250
KROF-160	0.8	27.68	160	DN80	4270	3435	1865	2250
KROF-160	1.0	24.96	160	DN80	4270	3435	1865	2250
KROF-185	0.7	33.28	185	DN125	5940	4000	2200	2450
KROF-185	0.8	33.18	185	DN125	5940	4000	2200	2450
KROF-185	1.0	28.70	185	DN125	5940	4000	2200	2450
KROF-200	0.7	35.80	200	DN125	6050	4000	2200	2450
KROF-200	0.8	35.69	200	DN125	6050	4000	2200	2450
KROF-200	1.0	31.43	200	DN125	6050	4000	2200	2450
KROF-250	0.7	44.33	250	DN125	6880	4000	2200	2450
KROF-250	0.8	44.20	250	DN125	6880	4000	2200	2450
KROF-250	1.0	39.64	250	DN125	6880	4000	2200	2450
KROF-280W	0.7	48.90	280	DN125	7160	3800	2000	2450
KROF-280W	0.8	48.75	280	DN125	7160	3800	2000	2450
KROF-280W	1.0	44.18	280	DN125	7160	3800	2000	2450
KROF-315W	0.7	53.48	315	DN125	7180	3800	2000	2450
KROF-315W	0.8	53.32	315	DN125	7180	3800	2000	2450
KROF-315W	1.0	48.81	315	DN125	7180	3800	2000	2450
